5-146135-7 TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

5-146135-7

Part No 5-146135-7
Manufacturer TE Connectivity
Catalog Rectangular Connectors - Headers, Male Pins
Description SURFACE MOUNT HEADER ASSEMBLY, M
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type Header, Breakaway
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 16
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Surface Mount
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.320" (8.13mm)
Insulation Height 0.090" (2.29mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish Thickness - Mating 100.0µin (2.54µm)
Contact Finish - Post Tin
Contact Material Copper Alloy
Insulation Material Liquid Crystal Polymer (LCP)
Temperature Range - Operating -65°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A per Contact
Voltage Rating 30VAC
Package Tube
Supply and Demand Status Limited
Win Source Part Number 1627007-5-146135-7
Ultra Librarian 3D Model Ultra Librarian 5-146135-7 CAD Model

Description
