4-794638-2 Real Image
Same model may have multiple batches, images only for reference.

4-794638-2

Part No 4-794638-2
Manufacturer TE Connectivity
Catalog Rectangular Connectors
Description CONN HEADER SMD 12POS 3MM / Connector Header Surface Mount 12 position 0.118" (3.00mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors>Headers, Male Pins
Manufacturer TE Connectivity AMP Connectors
Packaging Reel - TR
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.118" (3.00mm)
Number of Positions 12
Number of Rows 2
Row Spacing - Mating 0.118" (3.00mm)
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Surface Mount
Termination Solder
Fastening Type Locking Ramp
Insulation Height 0.364" (9.25mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polyamide (PA), Nylon
Features Solder Retention
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) Varies by Wire Gauge
Voltage Rating 250V
Contact Finish Thickness - Post 100.0µin (2.54µm)
Applications General Purpose
Base Product Number 794638
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Part Number A33248DKR,A33248TR,47946382,A33248CT,2266-4-794638-2TR
Standard Package 175
Win Source Part Number 1334393-4-794638-2
Ultra Librarian 3D Model Ultra Librarian 4-794638-2 CAD Model

Description

The TE Connectivity AMP Connectors 1334393-4-794638-2 is a high-quality male pin header connector that is used to connect wires and cables.

  • Mounting Type: surface mount
  • Feature: locking ramp
  • Voltage Rating: 250V
  • Material: brass
  • Material Flammability Rating: UL94 V-0
  • Contact Finish for Mating: gold
  • Thickness for Mating: 30.0µin (0.76µm)
  • Contact Finish for Post: tin
  • Thickness for Post: 100.0µin (2.54µm)
  • Temperature Range: -40°C to 105°C
  • ECCN: EAR99
  • ROHS3 Compliant: yes
