Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Connectors, Interconnects - Terminals - Spade Connectors
Mfr TE Connectivity
Series Budget
Package Bulk
Product Status Active
Terminal Type Standard
Stud/Tab Size 6 Stud
Width - Outer Edges 0.250" (6.35mm)
Length - Overall 0.623" (15.82mm)
Mounting Type Free Hanging (In-Line)
Termination Crimp
Wire Gauge 16-22 AWG
Insulation Non-Insulated
Features Serrated Termination
Contact Finish Tin
Contact Material Copper
Length - Ring Center to Termination 0.312" (7.92mm)
Length - Termination 0.181" (4.60mm)
Tongue Inside Opening 0.145" (3.68mm)
Base Product Number 3451
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 545569-34518
Ultra Librarian 3D Model Ultra Librarian 34518 CAD Model

Description

The 545569-34518 is a budget series spade connector from TE Connectivity.

  • Termination: Serrated termination for secure connections
  • Termination Type: Crimp
  • Contact Finish: Tin
  • Wire Gauge: 16 to 22 AWG
  • Contact Material: Copper
  • Insulation: Non-insulated
  • Standard Package: 1,000 pieces
  • Terminal Type: Standard
  • Width (Outer Edges): 0.250 inches (6.35mm)
  • Overall Length: 0.623 inches (15.82mm)
  • Mounting Type: Free hanging (in-line)
  • Stud/Tab Size: 6 stud
  • Length (Ring Center to Termination): 0.312 inches (7.92mm)
  • Length (Termination): 0.181 inches (4.60mm)
  • Tongue Inside Opening: 0.145 inches (3.68mm)
  • MSL Level: 1 (Unlimited)
  • HTSUS Code: 8536.90.4000
  • Manufacturer: TE Connectivity
