2-1445091-4 Real Image
Same model may have multiple batches, images only for reference.

2-1445091-4

Part No 2-1445091-4
Manufacturer TE Connectivity
Catalog Barrel - Power Connectors
Description CONN HEADER SMD R/A 4POS 3MM  /  Connector Header Surface Mount, Right Angle 4 position 0.118" (3.00mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr TE Connectivity AMP Connectors
Series Micro MATE-N-LOK
Package Tape & Reel (TR),Cut Tape (CT)
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.118" (3.00mm)
Number of Positions 4
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Surface Mount, Right Angle
Termination Solder
Fastening Type Locking Ramp
Insulation Height 0.152" (3.85mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 15.0µin (0.38µm)
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polyamide (PA), Nylon
Features Solder Retention
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) Varies by Wire Gauge
Voltage Rating 250V
Contact Finish Thickness - Post 100.0µin (2.54µm)
Applications General Purpose
Base Product Number 1445091
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2266-2-1445091-4TR,A123007CT,A123007TR,2-1445091-4-ND
Standard Package 215
Win Source Part Number 1035728-2-1445091-4
Ultra Librarian 3D Model Ultra Librarian 2-1445091-4 CAD Model

Description

The Micro MATE-N-LOK series by TE Connectivity AMP Connectors has a 4-position male pin header with solder retention.

  • Series: Micro MATE-N-LOK
  • Category: Rectangular Connectors - Headers, Male Pins
  • Positions Loaded: All
  • Number of Rows: 1
  • Voltage Rating: 250V
  • Shrouding: Shrouded - 4 Walls
  • Contact Finish-Mating: Gold
  • Contact Finish-Post: Tin
  • Mounting Type: Surface Mount, Right Angle
  • Pitch-Mating: 0.118" (3.00mm)
  • Contact Finish Thickness-Mating: 15.0μin (0.38μm)
  • Insulation Material: Polyamide (PA), Nylon
  • Insulation Color: Black
  • Operating Temperature: -40°C to 105°C
  • Alternative Parts: 2-1445057-4, 2-1445096-4, 2-1445053-4, 87898-0424, 90814-0904, and 68301-10152-1445091-4
  • MSL Level: 1 (Unlimited)
  • HTSUS: 8536.69.4040
