1825040-7 Real Image
Same model may have multiple batches, images only for reference.

1825040-7

Part No 1825040-7
Manufacturer TE Connectivity
Catalog Pushbutton Switches
Description SWITCH PUSHBUTTON DPDT 6A 125V
Datasheet
1825040-7 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Switches
Manufacturer TE Connectivity ALCOSWITCH Switches
Series MPA
Packaging Bulk
Part Status Obsolete(EOL)
Type Standard
Circuit DPDT
Switch Function On-Mom
Current Rating 6A (AC), 4A (DC)
Voltage Rating - AC 125V
Voltage Rating - DC 28V
Actuator Type Plunger for Cap
Mounting Panel Mount, Rear
Termination Style Solder Lug
Panel Cutout Dimensions Circular - 6.35mm Dia
Operating Temperature Range -20°C ~ 80°C
Electrical Life 50,000 Cycles
Win Source Part Number 760690-1825040-7
Popularity Medium
Supply and Demand Status Limited
Family Name 1825040
Introduction Date January 01, 2000
ECCN EAR99
Halogen Free Unknown
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian 1825040-7 CAD Model

Description

The TE Connectivity ALCOSWITCH Switches 1825040-7 is a DPDT circuit switch with a medium popularity in the market.

  • Current Rating: 6A (AC), 4A (DC)
  • Voltage Rating: 125V (AC) and 28V (DC)
  • Mounting: Panel
  • Panel Cutout: 6.35mm
