1-1825059-3 Real Image
Same model may have multiple batches, images only for reference.

1-1825059-3

Part No 1-1825059-3
Manufacturer TE Connectivity
Catalog DIP Switches
Description SWITCH SLIDE DIP SPST 25MA 24V / Dip Switch SPST 4 Position Surface Mount Slide (Standard) Actuator 25mA 24VDC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>DIP Switches
Manufacturer TE Connectivity ALCOSWITCH Switches
Packaging Tube
Circuit SPST
Number of Positions 4
Current Rating (Amps) 25mA
Voltage Rating 24VDC
Actuator Type Slide (Standard)
Actuator Level Flush, Recessed
Contact Material Copper Alloy
Contact Finish Gold
Height Above Board 0.177" (4.50mm)
Mounting Surface Mount
Termination Style Gull Wing
Pitch 0.100" (2.54mm), Full
Washable No
Temperature Range - Operating -30°C ~ 85°C
Body Material Polyphenylene Sulfide (PPS)
Length 0.478" (12.14mm)
Mechanical Life 1,000 Cycles
Electrical Life 1,000 Cycles
Base Product Number 1825059
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Other Part Number ADF04S04,-ADF04S04-LSI
Standard Package 35
Win Source Part Number 1323866-1-1825059-3
Ultra Librarian 3D Model Ultra Librarian 1-1825059-3 CAD Model

Description

The 1-1825059-3 from TE Connectivity ALCOSWITCH Switches is a surface mount DIP switch with four positions.

  • Pitch: 0.100" (2.54mm)
  • Termination Style: gull wing
  • Contact Finish: gold
  • Contact Material: copper alloy
  • Voltage Rating: 24VDC
  • Current Rating: 25mA
  • Height above Board: 0.177" (4.50mm)
  • Length: 0.478" (12.14mm)
  • Circuit: SPST
  • Actuator Type: slide
  • Electrical Life: 1,000 cycles
  • Mechanical Life: 1,000 cycles
  • Actuator Level: flush, recessed
  • Washable: no
  • Operating Temperature Range: -30°C to 85°C
  • ROHS3 Compliant: true
