ZJYS51R5-2PLT-01 TDK Corporation ZJYS51R5-2PLT-01 Real Image ZJYS51R5-2PLT-01 label picture 2 ZJYS51R5-2PLT-01 real image
Same model may have multiple batches, images only for reference.
ZJYS51R5-2PLT-01 TDK Corporation ZJYS51R5-2PLT-01 Real Image ZJYS51R5-2PLT-01 label picture 2 ZJYS51R5-2PLT-01 real image
ZJYS51R5-2PLT-01 TDK Corporation ZJYS51R5-2PLT-01 Real Image ZJYS51R5-2PLT-01 label picture 2 ZJYS51R5-2PLT-01 real image
Same model may have multiple batches, images only for reference.

ZJYS51R5-2PLT-01

Part No ZJYS51R5-2PLT-01
Manufacturer TDK Corporation
Catalog Common Mode Chokes
Description CMC 2A 2LN 100 OHM SMD
Datasheet
ZJYS51R5-2PLT-01 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Filters
Manufacturer TDK Corporation
Packaging Reel - TR
Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 100 Ohm @ 100MHz
Current Rating (Max) 2A
DC Resistance (DCR) (Max) 100 mOhm
Voltage Rating - DC 50V
Temperature Range - Operating -25°C to 85°C
Mounting SMD (SMT)
Height (Max) 0.200" (5.08mm)
Dimension Horizontal, 4 Gull Wing
Win Source Part Number 036727-ZJYS51R5-2PLT-01
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian ZJYS51R5-2PLT-01 CAD Model

Description

The TDK Corporation 036727-ZJYS51R5-2PLT-01 is a high-quality signal line filter designed for use in various electronic devices.

  • Voltage Rating: 50V
  • Maximum Current Rating: 2A
  • Impedance @ Frequency: 100 Ohm @ 100MHz
  • DC Resistance (DCR): 100 mOhm
  • Supply and Demand Status: Sufficient
