WT-505060-20K2-A10-G

Part No WT-505060-20K2-A10-G
Manufacturer TDK Corporation
Catalog Wireless Charging Coils
Description TX 1 COIL 2 LYR 24UH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Function Transmitter
Type 1 Coil, 2 Layer
Inductance 24µH
Tolerance ±10%
DC Resistance (DCR) 100mOhm Max
Q @ Freq 80 @ 100kHz
Temperature Range - Operating -30°C ~ 70°C
Size / Dimension 1.97\
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1509838-WT-505060-20K2-A10-G
Ultra Librarian 3D Model Ultra Librarian WT-505060-20K2-A10-G CAD Model

Description
