Same model may have multiple batches, images only for reference.
VLS3012T-470MR34 Real Image
Same model may have multiple batches, images only for reference.

VLS3012T-470MR34

Part No VLS3012T-470MR34
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 47UH 340MA 1.512 OHM
Datasheet
VLS3012T-470MR34 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Packaging Reel - TR
Status Not For New Designs
Type Wirewound
Inductance 47μH
Tolerance ±20%
Current Rating 340mA
Current - Saturation 340mA
DC Resistance (DCR) 1.512 Ohm Max
Temperature Range - Operating -40°C to 105°C
Frequency - Test 1MHz
Mounting SMD (SMT)
Height - Seated (Max) 0.047" (1.20mm)
Win Source Part Number 1117276-VLS3012T-470MR34
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VLS3012T-470MR34 CAD Model

Description

The TDK Corporation VLS3012T-470MR34 is a wirewound inductor with a current rating of 340mA and an inductance of 47μH.

  • Height: 0.047" (1.20mm)
  • Mounting Type: SMD (SMT)
  • Tolerance: ±20%
  • Current Saturation: 340mA
  • DC Resistance (DCR): 1.512 Ohm Max.
  • Status: Not Recommended for New Designs
  • Operating Temperature Range: -40°C to 105°C
