The VLS201610HBX-100M is a wire-wound chip inductor from TDK Corporation, designed for use in power supply circuits and high-frequency applications. It provides stable inductance and low DC resistance, making it suitable for use in DC-DC converters, noise filters, and impedance matching circuits.

Applications:

• DC-DC converters: Used in step-up, step-down, and inverting converters.
• Power supply circuits: Filtering and noise reduction in power supply lines.
• Noise filters: Attenuating unwanted noise in electronic circuits.
• Impedance matching: Providing impedance matching in RF circuits.
• High-frequency circuits: Filtering and resonance in high-frequency applications.

Features:

• Wire-wound construction: Provides high inductance and Q-factor.
• Low DC resistance: Minimizes power loss and improves efficiency.
• Compact size: Small 2016 (2.0mm x 1.6mm) footprint for space-constrained applications.
• High current capability: Handles high current levels without saturation.
• RoHS compliant: Environmentally friendly and compliant with RoHS regulations.

Benefits:

• Improved power supply performance: Reduces noise and ripple in power supply circuits.
• Increased efficiency: Low DC resistance minimizes power loss.
• Space-saving design: Small size allows for dense circuit layouts.
• Reliable operation: Robust construction ensures long-term performance.
• Environmentally friendly: RoHS compliance ensures minimal environmental impact.

Additional Details:

The VLS201610HBX-100M has an inductance value of 10 µH and is designed for applications where stable inductance and low loss are critical. Its saturation current is relatively high, allowing it to handle significant current levels without significant inductance drop. The inductor's construction utilizes a wire-wound structure on a ferrite core, contributing to its high Q-factor and low DC resistance. The operating temperature range is typically from -40°C to +125°C. This chip inductor is well-suited for demanding applications where miniaturization and performance are critical. TDK's advanced manufacturing techniques ensure consistent quality and reliability, making the VLS201610HBX-100M a popular choice in numerous electronic devices. The component is often used in conjunction with capacitors to form LC filters.
