VLF252015MT-100M Real Image
Same model may have multiple batches, images only for reference.

VLF252015MT-100M

Part No VLF252015MT-100M
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 10UH 940MA 280 MOHM / Inductors for Power Circuits Wound Ferrite
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer TDK Corporation
Packaging Reel
Part Status Obsolete (End Of Life)
Type Wirewound
Material - Core Ferrite
Inductance 10μH
Tolerance ±20%
Current Rating (Amps) 940mA
Current - Saturation 420mA
Shielding Shielded
DC Resistance (DCR) 280mOhm Max
Temperature Range - Operating -40°C ~ 105°C
Inductance Frequency - Test 1MHz
Mounting Style SMD
Manufacturer Package 1008 (2520 Metric)
Dimension 0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Maximum) 0.059" (1.50mm)
Manufacturer Pack Quantity 2,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 806834-VLF252015MT-100M
Ultra Librarian 3D Model Ultra Librarian VLF252015MT-100M CAD Model

Description

{"ProductId":745415,"FormattedDescription":"

The TDK Corporation VLF252015MT-100M is a high-quality wirewound inductor designed for use in a wide range of electronic applications.

  • Inductance: 10µH
  • Tolerance: ±20%
  • Shielded Design: Yes
  • Mounting Style: SMD
  • Case/Package: 1008 (2520 Metric)
  • DC Resistance (DCR): 280mOhm Max
  • Current Saturation: 420mA
  • Operating Temperature: -40°C to 105°C
"}
