VLCF5020T-220MR75-1 TDK Corporation VLCF5020T-220MR75-1 real image VLCF5020T-220MR75-1 label picture
Same model may have multiple batches, images only for reference.
VLCF5020T-220MR75-1 TDK Corporation VLCF5020T-220MR75-1 real image VLCF5020T-220MR75-1 label picture
VLCF5020T-220MR75-1 TDK Corporation VLCF5020T-220MR75-1 real image VLCF5020T-220MR75-1 label picture
Same model may have multiple batches, images only for reference.

VLCF5020T-220MR75-1

Part No VLCF5020T-220MR75-1
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description Inductor Power Shielded Wirewound 22uH 20% 100KHz Ferrite 1A 0.496Ohm DCR 2020 T/R / FIXED IND 22UH 750MA 496 MOHM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Packaging Reel - TR
Status Active
Type Wirewound
Material - Core Ferrite
Inductance 22μH
Tolerance ±20%
Current Rating 750mA
Current - Saturation 750mA
DC Resistance (DCR) 496 mOhm Max
Temperature Range - Operating -40°C to 105°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.079" (2.00mm)
Win Source Part Number 1117113-VLCF5020T-220MR75-1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name VLCF
Introduction Date May 20, 2002
ECCN EAR99
Country of Origin China, United States of America
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian VLCF5020T-220MR75-1 CAD Model

Description

This wirewound inductor is a part of the VLCF series and has an inductance of 22μH with a tolerance of ±20%.

  • Inductance: 22μH
  • Tolerance: ±20%
  • Current: 750mA
  • Current Saturation: 750mA
  • Package Type: Reel - TR
  • Mounting: Surface Mountable with SMD (SMT) mounting
  • Height: 0.079" (2.00mm)
  • Operating Temperature Range: -40°C to 105°C
  • DC Resistance (DCR): 496 mOhm Max
  • Material Core: Ferrite
  • Manufacturer: TDK Corporation
  • Status: Active
  • EOL Date: 2027
  • Compliance: Halogen-free standards
