Same model may have multiple batches, images only for reference.
NLV25T-056J-PFD Real Image
Same model may have multiple batches, images only for reference.

NLV25T-056J-PFD

Part No NLV25T-056J-PFD
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 56NH 340MA 600 MOHM / Inductor General Purpose Chip Molded/Unshielded Wirewound 0.056uH 5% 100MHz 20Q-Factor Ferrite 0.34A 0.6Ohm DCR 1008 Automotive T/R
Datasheet
NLV25T-056J-PFD Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Series NLV-PFD
Packaging Reel package
Type Wirewound
Material - Core Ferrite
Inductance 56nH
Tolerance ±5%
Current Rating 340mA
Shielding Unshielded
DC Resistance (DCR) 600 mOhm Max
Q @ Freq 20 @ 100MHz
Frequency - Self Resonant 1.1GHz
Ratings AEC-Q200
Operating Temperature Range -40°C ~ 105°C
Test Frequency 100MHz
Mounting SMD
Package 1008 (2520 Metric)
Manufacturer Package 1008 (2520 Metric)
Dimension 0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Maximum) 0.075" (1.90mm)
Win Source Part Number 790729-NLV25T-056J-PFD
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2k pcs
Family Name NLV-PFD
ECCN EAR99
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian NLV25T-056J-PFD CAD Model

Description

The TDK Corporation NLV25T-056J-PFD is a wirewound inductor with an inductance of 56nH.

  • Maximum Current Rating: 340mA
  • DC Resistance: 600mOhm
  • Dimension: 0.098" L x 0.079" W (2.50mm x 2.00mm)
  • Package: Reel, 2k pcs
