WLA.01 Taoglas Limited – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

WLA.01

Part No WLA.01
Manufacturer Taoglas Limited
Catalog RF Antennas
Description RF ANT 2.4GHZ CHIP SOLDER SMD
Datasheet
WLA.01 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

RF Family/Standard 802.15.4, Bluetooth, WiFi
Frequency Group UHF (2GHz ~ 3GHz)
Frequency (Center/Band) 2.4GHz
Frequency Range 2.4GHz ~ 2.5GHz
Antenna Type Chip
Number of Bands 1
VSWR 2
Gain 2.5dBi
Termination Solder
Mounting Type Surface Mount
Height (Max) 0.020" (0.50mm)
Applications Bluetooth, WLAN, Zigbee™
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1510954-WLA.01
Ultra Librarian 3D Model Ultra Librarian WLA.01 CAD Model
