TL.10.1HH11

Part No TL.10.1HH11
Manufacturer Taoglas Limited
Catalog RF Antennas
Description RF ANT 700MHZ/850MHZ DOME NMO ML
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

RF Family/Standard Cellular, Navigation, WiFi
Frequency Group Wide Band
Frequency (Center/Band) 700MHz, 850MHz, 900MHz, 1.575GHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.5GHz
Frequency Range 698MHz ~ 800MHz, 824MHz ~ 960MHz, 1.575GHz, 1.71GHz ~ 2.17GHz, 2.4GHz ~ 2.7GHz
Antenna Type Dome
Number of Bands 8
Gain -1.7dBi, -0.9dBi, 0.8dBi, 1.3dBi, 1.3dBi, 1.7dBi, 3.5dBi
Termination NMO Male
Ingress Protection IP67, IP69K
Mounting Type Base Mount
Height (Max) 3.343" (84.90mm)
Applications CDMA, DCS, EDGE, GPRS, GPS, GSM, HSDPA, LTE, PCS, UMTS, WCDMA, Wi-Fi
Package Bag
Supply and Demand Status Shortage
Win Source Part Number 1510929-TL.10.1HH11
Ultra Librarian 3D Model Ultra Librarian TL.10.1HH11 CAD Model
