The Taiyo Yuden MCKK2012TR47MNAC is a multilayer ceramic chip inductor designed for various high-frequency applications. This inductor is part of the MCKK series, known for its compact size and reliable performance. It features a multilayer construction that provides excellent electrical characteristics and mechanical strength. Its small footprint makes it ideal for use in densely populated circuit boards.

Applications

• Mobile communication devices
• Wireless LAN
• Bluetooth modules
• High-frequency circuits
• RF modules
• Matching circuits
• Filters

Features

• Multilayer ceramic construction
• Compact 2012 package size (2.0mm x 1.2mm)
• High Q factor
• Surface mount device (SMD)
• Operating temperature range: -55°C to +125°C
• Inductance value: 0.47uH
• Tolerance: ±20%

Benefits

• Space Saving: The small 2012 package size allows for high-density mounting, saving valuable PCB space.
• High Performance: The high Q factor ensures efficient signal transmission and minimal losses in high-frequency circuits.
• Reliability: Multilayer ceramic construction provides excellent mechanical strength and environmental stability.
• Easy Assembly: SMD design enables easy and cost-effective automated assembly.
• Versatility: Suitable for a wide range of high-frequency applications, including mobile communication and wireless LAN.

The MCKK2012TR47MNAC inductor has an inductance value of 0.47µH with a tolerance of ±20%. It is designed for surface mount technology, allowing for easy integration into automated assembly processes. The inductor's operating temperature range spans from -55°C to +125°C, ensuring stable performance across varying environmental conditions. It features a high Q factor, which minimizes signal loss and maximizes efficiency in high-frequency applications. The compact size and robust construction make it a reliable choice for designers seeking to optimize board space without sacrificing performance. The inductor is commonly used in RF modules, matching circuits, and filters within communication devices.
