TSN520M60 S3G

Name: TSN520M60 S3G
Brand: Taiwan Semiconductor
SKU: 807928
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	TSN520M60 S3G
Manufacturer	Taiwan Semiconductor
Catalog	Diodes, Rectifiers - Single
Description	DIODE SCHOTTKY 60V 20A 8PDFN
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Taiwan Semiconductor Corporation
Packaging	Reel
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Maximum)	60V
Current - Average Rectified (Io)	20A
Voltage - Forward (Vf) (Maximum) at If	580mV at 20A
Speed	Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr	500μA at 60V
Mounting Style	SMD
Manufacturer Package	8-PowerTDFN
Supplier Device Package	8-PDFN (5x6)
Operating Temperature - Junction	-55°C ~ 150°C
Manufacturer Pack Quantity	1,500
MSL Level	1 (Unlimited)
Popularity	Medium
Supply and Demand Status	Balance
Win Source Part Number	807928-TSN520M60 S3G
Ultra Librarian 3D Model	Ultra Librarian TSN520M60 S3G CAD Model

Description

The TSN520M60 S3G is an electronic component manufactured by Taiwan Semiconductor Corporation.

Win Source part number: 807928-TSN520M60 S3G
Diode Type: Schottky
Current - Average Rectified (Io): 20A
Voltage - DC Reverse (Vr) (Maximum): 60V
Voltage - Forward (Vf) (Maximum) @ If: 580mV @ 20A
Current - Reverse Leakage @ Vr: 500μA @ 60V
Supply and Demand Status: Balanced
