SMCJ24 Dc Components
Same model may have multiple batches, images only for reference.

SMCJ24

Part No SMCJ24
Manufacturer Taiwan Semiconductor
Catalog TVS - Diodes
Description 1500W, 29.7V, 10%, UNIDIRECTIONA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Taiwan Semiconductor
Series SMCJ
Package Tape & Reel
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 24V
Voltage - Breakdown (Min) 26.7V
Voltage - Clamping (Max) @ Ipp 43V
Current - Peak Pulse (10/1000µs) 36A
Power - Peak Pulse 1500W (1.5kW)
Power Line Protection No
Applications General Purpose
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package DO-214AB (SMC)
Base Product Number SMCJ24
Standard Package 3,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 668916-SMCJ24
Ultra Librarian 3D Model Ultra Librarian SMCJ24 CAD Model

Description

The 668916-SMCJ24 is a unidirectional Zener diode from the SMCJ series.

  • Reverse Standoff Voltage: 24V
  • Breakdown Voltage: 26.7V
  • Clamping Voltage: 43V @ peak pulse current (Ipp)
  • Peak Pulse Power: 1500W (1.5kW)
  • Applications: General purpose transient voltage suppression
  • Mounting Type: Surface mountable
  • Package: DO-214AB (SMC)
  • Packaging: Tape and reel
  • Standard Package: 3,000 pcs
  • Operating Temperature: -55°C to 150°C
  • Manufacturer: Taiwan Semiconductor
  • Status: Active
