B0540W Real Image B0540W real image17545 B0540W real image17546 B0540W real image17547 B0540W Real Image1 B0540W Real Image2
Same model may have multiple batches, images only for reference.
B0540W Real Image B0540W real image17545 B0540W real image17546 B0540W real image17547 B0540W Real Image1 B0540W Real Image2
B0540W Real Image B0540W real image17545 B0540W real image17546 B0540W real image17547 B0540W Real Image1 B0540W Real Image2
Same model may have multiple batches, images only for reference.

B0540W

Part No B0540W
Manufacturer Taiwan Semiconductor
Catalog Diodes, Rectifiers - Single
Description SOD-123, 40V, 0.5A, SCHOTTKY DIO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 40 V
Current - Average Rectified (Io) 500mA
Voltage - Forward (Vf) (Max) @ If 510 mV @ 500 mA
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 20 µA @ 40 V
Capacitance @ Vr, F 170pF @ 0V, 1MHz
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package SOD-123
Operating Temperature - Junction -55°C ~ 125°C
Base Product Number B0540
Standard Package 3,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 567762-B0540W
Ultra Librarian 3D Model Ultra Librarian B0540W CAD Model

Description

The 567762-B0540W is a fast recovery Schottky diode with a voltage rating of 40V and an average rectified current of 500mA.

  • Voltage Rating: 40V
  • Average Rectified Current: 500mA
  • Forward Voltage: 510mV @ 500mA
  • Reverse Leakage Current: 20μA @ 40V
  • Package: surface mount SOD-123 package
  • Packaging: tape and reel packaging with a standard package of 3,000 pieces
  • Capacitance: 170pF @ 0V and 1MHz
  • Operating Temperature Range: from -55°C to 125°C
  • Application: commonly used in rectifier applications where fast recovery time and low forward voltage drop are required
  • Manufacturer: Taiwan Semiconductor
  • Series: B0540 series
  • Status: active product
  • REACH: unaffected by REACH regulations
