HCB 4532KF-800T90

Part No HCB 4532KF-800T90
Manufacturer TAI-TECH Advanced Electronics
Catalog Ferrite Beads and Chips
Description 80 OHMS @ 100 MHZ 1 POWER LINE F / 80 Ohms @ 100 MHz 1 Power Line Ferrite Bead 1812 (4532 Metric) 9A 10mOhm
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Ferrite Beads and Chips
Mfr TAI-TECH Advanced Electronics
Series HCB4532KF
Package Tape & Reel
Filter Type Power Line
Number of Lines 1
Impedance @ Frequency 80 Ohms @ 100 MHz
Current Rating (Max) 9A
DC Resistance (DCR) (Max) 10mOhm
Ratings -
Temperature Range - Operating -55°C ~ 125°C
Package / Case 1812 (4532 Metric)
Mounting Type Surface Mount
Height (Max) 0.067" (1.70mm)
Size / Dimension 0.177" L x 0.126" W (4.50mm x 3.20mm)
Features -
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
Standard Package 1,000 pcs
Win Source Part Number 1382212-HCB 4532KF-800T90
Ultra Librarian 3D Model Ultra Librarian HCB 4532KF-800T90 CAD Model

Description

The HCB 4532KF-800T90 is a ferrite bead and chip filter from TAI-TECH Advanced Electronics' HCB4532KF series.

  • Application: Power Line Filtering
  • Impedance (@ 100 MHz): 80 Ohms
  • Maximum Current Rating: 9A
  • Size: 0.177" L x 0.126" W (4.50mm x 3.20mm)
  • Mounting Type: Surface Mount
  • Package: Tape and Reel
  • Operating Temperature: -55°C to 125°C
