The 1.5SMCJ91A is a Transient Voltage Suppressor (TVS) diode manufactured by SUNMATE electronic Co., LTD. It is designed to protect sensitive electronic components from voltage transients induced by lightning, electrostatic discharge (ESD), inductive load switching, and other transient voltage events. The device is part of the 1.5SMCJ series, which are known for their high surge capability and fast response time.

Applications:

• Protection of I/O interfaces
• Voltage surge protection in consumer electronics
• Protection of sensitive equipment against ESD
• Automotive electronics surge protection
• Industrial control systems

Features:

• Peak Pulse Power Dissipation: 1500W (1.5kW)
• Stand-off Voltage: 91V
• Breakdown Voltage: 102V - 113V
• Clamping Voltage: 146V
• Unidirectional configuration
• Fast response time: Typically less than 1.0ps from 0V to Breakdown Voltage
• Excellent clamping capability
• Low incremental surge resistance
• Typical IR less than 5 μA above 12V
• High temperature soldering guaranteed: 260°C/10 seconds at terminals
• Plastic package has Underwriters Laboratory Flammability Classification 94V-0
• RoHS compliant

Benefits:

• Provides robust protection against voltage transients
• Enhances the reliability and lifespan of electronic equipment
• Reduces downtime and maintenance costs
• Prevents damage to sensitive components
• Facilitates compliance with regulatory standards for surge protection

Additional Details:

The 1.5SMCJ91A comes in an SMC (DO-214AB) package, which is designed for surface mounting on printed circuit boards. The operating junction temperature range is from -55°C to +150°C. The device is specifically designed to protect circuits operating at or near 91V. It’s unidirectional, meaning it provides protection only for positive polarity voltage spikes. This TVS diode is suitable for a wide range of applications where reliable transient voltage protection is required.
