The SBH51-LPSE-D03-ST-BK is a header connector manufactured by Sullins Connector Solutions. It is a single row, 3-position (03 contacts) header with a 0.100" (2.54mm) pitch. The connector features a low profile design and is designed for through-hole mounting on printed circuit boards (PCBs). The "ST" in the part number indicates a straight (vertical) orientation, and "BK" denotes the black insulator color. The SBH51 series is known for providing a reliable connection solution for board-to-board and wire-to-board applications.

Applications

• PCB Interconnection: Used to connect one PCB to another.
• Wire-to-Board Connections: Provides a termination point for wires onto a PCB.
• Signal Transmission: Used for transmitting various signals, including data and power.
• Prototyping: Suitable for prototyping and development boards.
• Instrumentation: Used in test and measurement equipment.

Features

• 3 Positions: Provides three individual connection points.
• 0.100" (2.54mm) Pitch: Standard pitch for compatibility with breadboards and other components.
• Single Row: Compact design for space-saving applications.
• Through-Hole Mounting: Secure mounting method for reliable connection.
• Straight (Vertical) Orientation: Allows for perpendicular connection to the PCB.
• Black Insulator: Provides insulation and identifies the connector.

Benefits

• Reliable Connection: Ensures a stable and secure electrical connection.
• Easy to Use: Simple through-hole mounting simplifies the assembly process.
• Versatile: Suitable for a variety of applications requiring board-to-board or wire-to-board connections.
• Compact Design: Saves space on the PCB.
• Standard Pitch: Compatible with a wide range of components and development boards.

Additional Details

The insulator material is typically made of high-temperature thermoplastic, allowing it to withstand reflow soldering temperatures. The contacts are typically made of brass or phosphor bronze with a tin or gold plating for good conductivity and corrosion resistance. The current rating is typically around 3 Amps per contact. The voltage rating is typically around 250V. The operating temperature range is typically from -40°C to +105°C. This connector is RoHS compliant. The mating connector for this header would typically be a receptacle connector with a compatible pitch and number of positions. The insertion force and withdrawal force are designed to provide a secure and reliable connection.
