The VNB35NV04TR-E from STMicroelectronics is a high-performance N-channel enhancement mode Power MOSFET, designed to deliver efficient power conversion and control in various applications. This MOSFET is part of the OMNIFET II™ family, which is known for its robustness and reliability, making it an ideal choice for demanding automotive and industrial environments.

Key Features

• Device Type: N-channel MOSFET
• Package: DPAK (TO-252)
• Drain-to-Source Voltage (V_DS): 40V
• Continuous Drain Current (I_D): 30A
• Power Dissipation (P_D): 70W
• R_DS(on): Low on-state resistance for higher efficiency
• Temperature Range: Operating temperatures from -55°C to 175°C
• Protection: Includes over-temperature protection, ESD protection, and current limiting features

Applications

The VNB35NV04TR-E is versatile and can be used in a variety of applications, including but not limited to:

• Automotive applications like motor drive controllers, and lighting systems
• DC-DC converters and power management systems
• Switching regulators and switch-mode power supplies (SMPS)
• Load switches and battery management
• Industrial automation and control systems

Quality and Reliability

STMicroelectronics ensures that the VNB35NV04TR-E MOSFET meets stringent quality standards. It is designed with state-of-the-art manufacturing processes to ensure high durability and performance consistency. The device is AEC-Q101 qualified, meaning it has passed rigorous tests for automotive reliability and performance.

Environmental Compliance

The VNB35NV04TR-E is compliant with RoHS (Restriction of Hazardous Substances) and is lead-free, reflecting STMicroelectronics' commitment to environmental sustainability and reducing the ecological impact of its products.
