TDA7396

Part No TDA7396
Manufacturer STMicroelectronics
Catalog Linear - Amplifiers - Audio
Description 45W/2ohm BRIDGE CAR RADIO AMPLIFIER WITH DIAGNOSTIC FACILITY | IC AMP AUDIO PWR 65W MULTIWATT11
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube
Status Obsolete
Type Class AB
Output Type 1-Channel (Mono)
Max Output Power x Channels at Load 65W x 1 at 2Ohm
Supply Voltage (V) 8V ~ 18V
Features Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby
Mounting Style Through Hole
Temperature Range - Operating -40°C ~ 150°C
Supplier Device Package 11-Multiwatt
Manufacturer Package Multiwatt-11 (Vertical, Bent and Staggered Leads)
Family Part Number TDA7396
Manufacturer Pack Quantity 25
MSL Level 1 (Unlimited)
Win Source Part Number 1266191-TDA7396
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TDA7396 CAD Model

Description

The TDA7396 is a high-quality audio power amplifier designed by STMicroelectronics, a leader in semiconductor solutions. This robust component is specifically engineered for car radio applications, offering an exceptional audio experience for in-vehicle entertainment systems. With its advanced features and high performance, the TDA7396 stands out as a top choice for automotive audio amplification.

Key Features

  • High Output Power: The TDA7396 is capable of delivering up to 45W of continuous output power into a 4Ω load with excellent sound quality, ensuring loud and clear audio reproduction.
  • Low Distortion: It maintains a low level of distortion across the entire audio spectrum, resulting in a crisp and clean sound output.
  • High Efficiency: With its class AB operation, the TDA7396 provides a good balance between efficiency and sound quality, making it an energy-efficient choice for car audio systems.
  • Multiple Protection Systems: The device includes several built-in protection features, such as short-circuit protection, thermal shutdown, and load dump voltage surge protection, ensuring reliability and safety under various conditions.
  • Flexible Supply Voltage: The TDA7396 operates over a wide supply voltage range, accommodating the varying electrical environments of automotive applications.

Applications

The TDA7396 is primarily used in the automotive industry for powering the audio system of vehicles. It is suitable for applications that require high-quality sound amplification, such as:

  • Car radio systems
  • Automotive entertainment systems
  • GPS navigation audio output
  • Hands-free calling systems

Overall, the TDA7396 from STMicroelectronics is a highly reliable audio power amplifier that delivers superior audio performance. Its robust design and comprehensive protection features make it an ideal solution for enhancing the audio experience in modern vehicles.
