The STPS3150UY is a robust and efficient Schottky rectifier designed by STMicroelectronics, a leader in semiconductor solutions. This high-performance diode is engineered to meet the needs of a wide range of applications, including power supplies, converters, and high-frequency circuits where low forward voltage drop and fast switching are required.

Key Features

• High Junction Temperature: With a junction temperature capability of up to 150°C, the STPS3150UY ensures reliable operation even under high-temperature conditions.
• Low Forward Voltage Drop: The device offers a low forward voltage drop, which results in reduced power loss and improved efficiency during operation.
• Avalanche Capability: This rectifier is capable of withstanding voltage surges, providing robust performance and enhanced reliability.
• High Average Forward Current: With an average forward current of 3 A, the STPS3150UY can handle significant power loads, making it suitable for demanding applications.

Applications

The STPS3150UY is ideal for a variety of applications, including:

• Switching power supplies
• DC/DC converters
• Free-wheeling diodes
• Reverse battery protection
• Power management devices

Package and Quality

The STPS3150UY comes in a compact SMB (DO-214AA) package, which is well-suited for space-constrained applications. It is designed to meet the stringent requirements of the industrial market, ensuring both high-quality and reliability. The device is RoHS compliant and adheres to STMicroelectronics' commitment to environmentally responsible manufacturing.

Technical Specifications

Parameter Value Average Forward Current (I<sub>F(AV)) 3 A Forward Voltage Drop (V<sub>F) 0.82 V at 3 A Peak Reverse Voltage (V<sub>RRM) 150 V Junction Temperature (T<sub>j) -40°C to +150°C

For detailed specifications and application notes, it is recommended to consult the official STPS3150UY datasheet available on the STMicroelectronics website.
