STPS20H100CFP - Power Schottky Rectifier

The STPS20H100CFP is a robust and high-performance Power Schottky Rectifier, designed and manufactured by STMicroelectronics. This component is particularly suited for switch mode power supplies and high-frequency DC to DC converters.

Featuring a voltage rating of 100V and a current capacity of 20A, the STPS20H100CFP is engineered to offer low forward voltage drop and reduced power losses, making it highly efficient for a wide range of applications. Its high junction temperature capability ensures reliability even under extreme operating conditions.

The device comes in a TO-220FP package, which provides excellent thermal performance and is compatible with various types of soldering processes. The STPS20H100CFP incorporates a dual center tap Schottky rectifier configuration, which is optimized for synchronous rectification in SMPS and is also well-suited for other polarity protection applications.

Key Features:

• High junction temperature capability (Tj max: 150°C)
• Low forward voltage drop for higher efficiency (Vf max: 0.85V)
• Average forward current of 20A
• High frequency operation
• TO-220FP package for optimal thermal performance
• Guard-ring for enhanced ruggedness and long term reliability

Applications:

• Switch mode power supplies (SMPS)
• DC to DC converters
• Free-wheeling diodes
• Reverse battery protection
• Polarity protection applications

The STPS20H100CFP is a testament to STMicroelectronics' commitment to providing high-quality components that meet the demanding requirements of modern electronic circuits. Its combination of high efficiency, reliability, and thermal performance makes it an excellent choice for designers looking to optimize their power management solutions.
