Overview of STM6824SWY6F

The STM6824SWY6F is a sophisticated microprocessor supervisory circuit designed and manufactured by STMicroelectronics, a leader in the semiconductor industry. This compact component is engineered to monitor the power supply and system health of microprocessor (µP) systems, ensuring that the system operates reliably within its specified voltage thresholds.

Key Features

• Precision Monitoring: The device offers precision monitoring of 3.0V, 3.3V, and 5.0V supply voltages, which are common in digital systems, providing versatility for various applications.
• Manual Reset Input: An active-low manual reset input allows for an external trigger to initiate a system reset, offering an additional layer of control.
• Reset Timing: The STM6824SWY6F features an internally fixed delay time for the reset signal, ensuring that the system has sufficient time to stabilize after a power disturbance before resuming operation.
• Low Power Consumption: Designed for power-sensitive applications, the device boasts low power consumption, making it ideal for portable and battery-operated devices.
• Multiple Output Configurations: The device is available with different output configurations, including push-pull active-low reset, which provides flexibility for integration into various system designs.

Applications

The STM6824SWY6F is suitable for a wide range of applications where reliable system monitoring is crucial. Common use cases include:

• Computers and computer peripherals
• Embedded systems
• Portable and battery-powered devices
• Networking equipment
• Industrial controllers

Package and Availability

The device comes in a compact SOT-23-5 package, which is designed to occupy minimal board space while providing robust functionality. This small footprint makes it an excellent choice for space-constrained applications. The STM6824SWY6F is available through STMicroelectronics and its authorized distributors, ensuring easy access for designers and manufacturers.

In summary, the STM6824SWY6F from STMicroelectronics is a reliable and efficient solution for system monitoring, offering precision voltage supervision, low power consumption, and a versatile feature set to enhance the stability and performance of microprocessor systems.
