STEVAL-IFR001V1 - STMicroelectronics Evaluation Board

The STEVAL-IFR001V1 is a state-of-the-art evaluation board from STMicroelectronics, designed to showcase the capabilities of the L6390 high-voltage high and low-side driver. The board is a crucial tool for developers and engineers who wish to evaluate and design applications that require driving high voltage power MOSFETs or IGBTs.

Key Features

• Integrated high-voltage half-bridge driver L6390
• Operates at high switching frequencies
• Adjustable deadtime for optimal driving
• Smart shutdown function
• Under-voltage lockout
• Overcurrent protection
• Error feedback
• 3.3 V / 5 V TTL/CMOS inputs with hysteresis
• Compatible with a wide range of microcontrollers

Applications

The STEVAL-IFR001V1 evaluation board is versatile, suitable for a wide range of high-power applications such as motor control, lighting, power supply units, and industrial automation systems. It provides an excellent platform for quick prototyping and testing, significantly reducing development time and cost.

Design and Performance

The board is meticulously designed to deliver exceptional performance. It includes all the necessary features to facilitate an easy and comprehensive evaluation of the L6390 driver. The onboard components are carefully selected to ensure reliability and durability, even under strenuous conditions. The STEVAL-IFR001V1 is also equipped with various protection features, such as overcurrent protection and under-voltage lockout, ensuring safe operation during experimentation and development.

Support and Resources

STMicroelectronics provides extensive support for the STEVAL-IFR001V1, including detailed documentation, application notes, and reference designs. This wealth of resources is invaluable for developers seeking to understand the full capabilities of the evaluation board and to accelerate the development of their applications.
