Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 28V
Minimum Breakdown Voltage 31.1V
Max Clamping Voltage 51.6V
Peak Pulse Current(Ippm) 68A (8/20μs)
Power Dissipation - Pd 600W
Applications General Purpose
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package SMA (DO-214AC)
Win Source Part Number 1097343-SMA6J28A-TR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SMA6J28A-TR CAD Model

Description

Overview of SMA6J28A-TR

The SMA6J28A-TR is a high-quality transient voltage suppression (TVS) diode designed and manufactured by STMicroelectronics, a leader in the semiconductor industry. This robust component is engineered to protect sensitive electronic equipment from voltage spikes and surges, making it an essential component for a wide range of applications including industrial, automotive, and consumer electronics.

Key Features

  • Transient Protection: The SMA6J28A-TR is specifically designed to safeguard against transient overvoltage events, offering a stand-off voltage of 28V.
  • High Surge Capability: With its high peak pulse power dissipation rating of 600W (10/1000µs), this TVS diode can handle significant surge events, ensuring reliable protection for your devices.
  • Unidirectional Functionality: As a unidirectional TVS, the SMA6J28A-TR is optimized for scenarios where threat vectors are known and protection is required in a single direction.
  • Compact Package: Encased in a DO-214AC (SMA) package, the device is not only robust but also space-efficient, making it suitable for compact circuit designs.
  • High Temperature Range: The operating junction temperature range from -55°C to +150°C allows the SMA6J28A-TR to perform reliably in extreme conditions.
  • Compliance: This device is compliant with the RoHS and Halogen-free standards, ensuring environmental safety and meeting global regulatory requirements.

Applications

The SMA6J28A-TR is versatile and can be used in a variety of applications, such as:

  • Protection of I/O interfaces
  • Voltage regulation for sensitive electronics
  • Power supply management
  • Industrial control systems
  • Consumer electronics such as smartphones and computers
  • Automotive electronics where reliability under harsh conditions is paramount

Quality and Reliability

STMicroelectronics ensures that the SMA6J28A-TR meets the highest quality and reliability standards. Each diode is rigorously tested to guarantee performance under the most demanding conditions. When you choose the SMA6J28A-TR, you are selecting a product that not only provides superior transient voltage protection but also the assurance of a trusted supplier in the electronics industry.
