Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 58.1V
Minimum Breakdown Voltage 64.6V
Max Clamping Voltage 121V
Peak Pulse Current(Ippm) 33A (8/20μs)
Power Dissipation - Pd 600W
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SMB (DO-214AA)
Win Source Part Number 028977-SM6T68A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SM6T68A CAD Model

Description

The SM6T68A is a robust Transil™ transient voltage suppressor (TVS) diode designed and manufactured by STMicroelectronics. It is engineered to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events. With its bidirectional clamping feature, it is an ideal choice for safeguarding circuits in a variety of applications, including industrial, automotive, and telecommunication systems.

Key Features

  • Stand-off Voltage: The SM6T68A is designed with a stand-off voltage of 58.1V, providing a suitable voltage threshold before clamping occurs.
  • Peak Pulse Power: It can handle a peak pulse power dissipation of 600W (10/1000μs surge), ensuring reliable protection against high energy transients.
  • Low Clamping Factor: The device offers a low clamping factor, which ensures that the voltage seen by the protected component remains within safe limits during transient events.
  • Fast Response Time: With its fast response time to transient overvoltages, the SM6T68A is highly effective in protecting sensitive circuitry.
  • Operating Temperature Range: The device operates effectively over a wide temperature range from -40°C to +150°C, making it suitable for harsh environments.
  • Package: Available in a molded plastic, over glass passivated junction, the SM6T68A comes in a DO-214AA (SMB) package that is both compact and robust.

Applications

The SM6T68A is versatile and can be employed in numerous protective applications. These include:

  • Power supply lines protection
  • Automotive voltage regulation systems
  • Telecommunication and networking devices
  • Computer and consumer electronics surge protection
  • Industrial control systems

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The SM6T68A TVS diode is no exception, as it is manufactured with the stringent quality control and reliability testing that STMicroelectronics is known for. This ensures that customers receive components that perform reliably even under the most demanding conditions.
