The SM2T6V8A from STMicroelectronics is a high-quality Transil™ diode designed to provide state-of-the-art overvoltage protection for sensitive electronics. This diode is part of the SM2T series, which is known for its ability to clamp transient overvoltages and dissipate high surge currents effectively.

Key Features

• Stand-off voltage: 6.8V, making it suitable for a range of applications where this voltage level is critical for component protection.
• Peak pulse power: 400W (10/1000μs surge), ensuring robust protection against high energy transients.
• Low clamping factor: The SM2T6V8A has a low clamping voltage to stand-off voltage ratio, providing efficient protection by clamping overvoltages to a safe level without compromising the performance of the protected circuit.
• Fast response time: The diode reacts almost instantaneously to transient overvoltages, safeguarding components before damage can occur.
• Low incremental surge resistance: This feature helps in maintaining the clamping voltage at a low level even during surge events.
• JEDEC registered package outline: The device comes in a DO-214AA package, which is compact and suitable for high-density PCB designs.

Applications

The SM2T6V8A is ideal for protecting voltage-sensitive components which can be found in a variety of electronic devices and systems, including:

• Consumer electronics
• Computer systems
• Industrial electronics
• Telecommunication systems
• Automotive applications

Reliability and Quality

STMicroelectronics is a global semiconductor leader and ensures that the SM2T6V8A meets the highest quality and reliability standards. This Transil™ diode is manufactured in ISO/TS 16949 certified facilities and is compliant with the AEC-Q101 standard for automotive electronic components. Additionally, it adheres to the rigorous RoHS and REACH environmental regulations, making it a safe choice for both the consumer and the environment.
