The L9825TR from STMicroelectronics is a state-of-the-art octal low-side driver that is designed to manage a wide range of automotive applications. This integrated circuit (IC) is specifically tailored to control various inductive and resistive loads in the harsh environments typical of automotive electronics.

Key Features

• Voltage Range: The L9825TR operates over a broad voltage range, catering to the demanding requirements of automotive power systems.
• Output Current: Each of the eight low-side drivers can deliver a significant amount of current, making it suitable for driving a variety of loads.
• Protection Mechanisms: The device is equipped with numerous built-in protection features, including overtemperature shutdown, output short-circuit protection, and under voltage shutdown, ensuring reliable operation and safeguarding against potential damage.
• Diagnostic Functions: Advanced diagnostic capabilities are integrated into the L9825TR, allowing for real-time monitoring of load status, which is critical for system maintenance and troubleshooting.

Applications

The L9825TR is versatile and can be used in a multitude of automotive applications. These include, but are not limited to:

• Lamp driving
• Relay driving
• DC motor control in applications such as power window lifters, seat adjustment, or HVAC blowers
• Control of resistive loads like heaters

Technical Specifications

The technical specifications of the L9825TR make it an excellent choice for designers looking for a robust, flexible solution:

• Supply voltage from 5.5 V to 28 V
• Output current up to 0.9 A per channel
• Low saturation voltage
• Serial peripheral interface (SPI)

The L9825TR is available in a compact surface-mount package, making it suitable for space-constrained applications while providing the performance and reliability expected from a leading semiconductor manufacturer like STMicroelectronics.
