The EMIF06-10006F1 is a highly integrated device designed by STMicroelectronics, specifically tailored for EMI (Electromagnetic Interference) filtering and line termination in mobile phone applications. This compact component is part of STMicroelectronics' dedication to providing advanced solutions for managing electromagnetic compatibility in sensitive electronic equipment.

Key Features

• Integration: The EMIF06-10006F1 combines six EMI filters and one line termination resistor network into a single package, significantly reducing PCB space requirements and simplifying design.
• High-Speed Data Lines: It is designed to be used with high-speed data lines, providing excellent filtering capabilities for signals such as those found in USB 2.0, MIPI, and other communication standards.
• Low Pass Filter: The device acts as a low-pass filter for each line, attenuating unwanted high-frequency noise and preventing it from affecting the performance of the mobile phone.
• ESD Protection: Integrated ESD protection circuitry safeguards the mobile phone's sensitive components against electrostatic discharges, meeting the IEC 61000-4-2 standard.

Applications

The EMIF06-10006F1 is ideal for use in a variety of mobile communication devices where space is at a premium and EMI filtering is necessary. These include:

• Smartphones
• Tablets
• Portable communication devices
• GPS receivers
• Other applications requiring EMI filtering and line termination

Technical Specifications

The EMIF06-10006F1 offers an impressive array of technical specifications that make it a robust choice for designers:

• Cut-off frequency: 250 MHz (typical)
• ESD protection up to 15 kV
• Operating temperature range: -40°C to +85°C
• Package: μQFN-10L (2.5 x 1 x 0.55 mm)

With its combination of advanced EMI filtering, compact design, and robust ESD protection, the EMIF06-10006F1 from STMicroelectronics is an excellent choice for designers looking to enhance the performance and reliability of their mobile communication devices.
