Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Transformers - Power Transformers
Mfr SolaHD
Series SMT
Package Bulk
Product Status Active
Type Laminated Core
Primary Winding(s) Dual
Secondary Winding(s) Single
Center Tap No
Power - Max 3000VA
Mounting Type Chassis Mount
Termination Style Solder, Quick Connect
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.32.0000
Win Source Part Number 680731-T3000
Ultra Librarian 3D Model Ultra Librarian T3000 CAD Model

Description

The 680731-T3000 is a power transformer designed for use in electronic devices.

  • Category: Transformers
  • Series: SMT
  • Core Type: Laminated
  • Termination: Solder or Quick Connect
  • Packaging: Bulk
  • Standard Package: 1 Piece
  • Max Power: 3000VA
  • Primary Windings: Dual
  • Secondary Windings: Single
  • Center Tap: No
  • Mounting: Chassis Mount
  • ECCN: EAR99
  • MSL: 1
  • HTSUS Code: 8504.32.0000
  • Manufacturer: SolaHD
