BAV21WS Real Image BAV21WS real image17582 BAV21WS real image17583 BAV21WS real image17584 BAV21WS Real Image
Same model may have multiple batches, images only for reference.
BAV21WS Real Image BAV21WS real image17582 BAV21WS real image17583 BAV21WS real image17584 BAV21WS Real Image
BAV21WS Real Image BAV21WS real image17582 BAV21WS real image17583 BAV21WS real image17584 BAV21WS Real Image
Same model may have multiple batches, images only for reference.

BAV21WS

Part No BAV21WS
Manufacturer SMC Diode Solutions
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 200V 200MA SOD323 / Diode 200 V 200mA Surface Mount SOD-323
Datasheet
BAV21WS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr SMC Diode Solutions
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 200 V
Current - Average Rectified (Io) 200mA
Voltage - Forward (Vf) (Max) @ If 1 V @ 100 mA
Speed Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr) 50 ns
Current - Reverse Leakage @ Vr 100 nA @ 100 V
Capacitance @ Vr, F 5pF @ 0V, 1MHz
Mounting Type Surface Mount
Package / Case SC-90, SOD-323F
Supplier Device Package SOD-323
Operating Temperature - Junction -65°C ~ 150°C
Base Product Number BAV21
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 568997-BAV21WS
Ultra Librarian 3D Model Ultra Librarian BAV21WS CAD Model

Description

The 568997-BAV21WS is a standard rectifier diode with a maximum DC reverse voltage of 200V and an average rectified current of 200mA from SMC Diode Solutions.

  • Maximum DC Reverse Voltage: 200V
  • Average Rectified Current: 200mA
  • Forward Voltage: 1V @ 100mA
  • Reverse Recovery Time: 50ns
  • Reverse Leakage Current: 100nA @ 100V
  • Capacitance: 5pF @ 0V and 1MHz
  • Operating Temperature: -65°C to 150°C
  • Mounting: Surface Mount
  • Package: SC-90, SOD-323F
  • Status: Active
