B5819WS Real Image B5819WS real image17559 B5819WS Real Image
Same model may have multiple batches, images only for reference.
B5819WS Real Image B5819WS real image17559 B5819WS Real Image
B5819WS Real Image B5819WS real image17559 B5819WS Real Image
Same model may have multiple batches, images only for reference.

B5819WS

Part No B5819WS
Manufacturer SMC Diode Solutions
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 1A SOD323
Datasheet
B5819WS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr SMC Diode Solutions
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 40 V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 600 mV @ 1 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 200 µA @ 40 V
Capacitance @ Vr, F 120pF @ 5V, 1MHz
Mounting Type Surface Mount
Package / Case SC-76, SOD-323
Supplier Device Package SOD-323
Operating Temperature - Junction -65°C ~ 150°C
Base Product Number B5819
Standard Package 45,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 568126-B5819WS
Package Tape & Reel (TR);Cut Tape (CT)
Voltage - DC Reverse (Vr) (Max) 40V
Voltage - Forward (Vf) (Max) @ If 600mV @ 1A
Current - Reverse Leakage @ Vr 1mA @ 40V
Capacitance @ Vr, F 120pF @ 4V, 1MHz
Grade -
Operating Temperature - Junction -55°C ~ 125°C
Ultra Librarian 3D Model Ultra Librarian B5819WS CAD Model

Description

The 568126-B5819WS is a Schottky diode with a voltage rating of 40V and an average rectified current of 1A.

  • Voltage: 40V
  • Average Rectified Current: 1A
  • Forward Voltage: 600mV @ 1A
  • Reverse Leakage Current: 200µA @ 40V
  • Capacitance: 120pF @ 5V and 1MHz
  • Temperature Range: -65°C to 150°C
  • Mounting Type: Surface Mount
  • Package Type: SC-76, SOD-323
  • Package: Tape and reel package of 45,000 pcs
  • Manufacturer: SMC Diode Solutions
  • Product Status: Active
