The SiTime SIT8002AI-43-33E-14.31818Y is a programmable oscillator within SiTime's SiT8002 series. This series is recognized for its high performance, compact size, and excellent reliability. The component designation breaks down as follows: 'AI' denotes a specific combination of operating voltage and temperature range, '43' might indicate specific configuration options or performance characteristics, '33E' likely relates to supply voltage and stability parameters, and '14.31818Y' signifies a highly precise output frequency of 14.31818 MHz. This oscillator is engineered to deliver a stable and accurate clock signal, catering to applications that require this specific frequency.

Applications

• Legacy Communication Systems (e.g., UART, Serial Communication)
• Embedded Systems requiring specific clock frequencies
• Microcontroller Clocking
• Audio and Video Applications
• Industrial Control Systems demanding precise timing

Features

• Frequency: 14.31818 MHz (High Precision)
• Supply Voltage: 3.3V
• High frequency stability
• Small footprint
• Low power consumption
• Wide operating temperature range
• Programmable for customized applications

Benefits

• Provides a highly accurate and stable clock signal, crucial for precise timing in sensitive applications.
• Enables compact system designs due to its small form factor.
• Offers flexibility through programmability, tailoring the oscillator to unique application needs.
• Minimizes power consumption, promoting energy efficiency.
• Ensures reliable operation in harsh environments owing to its broad temperature range.

The SiT8002 series oscillators utilize MEMS (Micro-Electro-Mechanical Systems) technology, offering advantages over traditional quartz oscillators regarding size, robustness, and dependability. The 14.31818 MHz frequency is often used in specialized communication protocols and legacy systems needing a highly accurate and stable clock. Its low jitter and high stability guarantee clean clock signals, minimizing errors and boosting overall system accuracy.

Specifications:

• Frequency Stability: Typically ±20 ppm to ±50 ppm (depending on configuration)
• Operating Temperature Range: -40°C to +85°C
• Supply Voltage: 3.3V
• Output Signal: CMOS
• Package: Typically 2.5 x 2.0 mm or smaller
