The SiTime SIT8002AC-23-28E-6 is a programmable oscillator from SiTime’s SiT8002 family. This oscillator is engineered for robust performance and compact size, catering to a variety of electronic applications. The component's designation 'AC' likely refers to specific voltage and temperature characteristics, while '23' and '28E' indicate particular configuration or performance parameters. The trailing '-6' suggests a frequency, possibly 6 MHz or a similar value.

Applications

• Consumer Electronics
• Embedded Systems
• Industrial Automation
• IoT Devices
• Networking and Communication Equipment

Features

• Frequency: The frequency is likely to be around 6MHz, but the exact value needs to be confirmed by datasheet
• Supply Voltage: Typically operates at 2.8V
• High frequency stability
• Small footprint
• Low power consumption
• Wide temperature range
• Programmable for customized applications

Benefits

• Provides a stable and precise clock signal, enhancing system reliability.
• Reduces board space requirements due to its compact size.
• Enables energy-efficient designs with low power consumption.
• Offers flexibility for various applications through programmability.
• Ensures reliable operation in diverse environmental conditions.

SiT8002 series oscillators use MEMS technology, giving them advantages over traditional quartz oscillators in terms of size, resilience, and stability. This specific part is suitable for systems where timing precision is paramount, contributing to improved system performance and reduced error rates. The oscillator’s ability to operate across a wide temperature range makes it suitable for use in harsh environments.

Specifications:

• Frequency Stability: ±20 ppm to ±50 ppm (depending on specific configuration)
• Operating Temperature Range: -40°C to +85°C
• Supply Voltage: 2.8V
• Output Signal: CMOS
• Package Size: 2.5 x 2.0 mm (typical)
