C8051F336-GM Silicon Labs C8051F336-GM Real Image C8051F336-GM label picture
Same model may have multiple batches, images only for reference.
C8051F336-GM Silicon Labs C8051F336-GM Real Image C8051F336-GM label picture
C8051F336-GM Silicon Labs C8051F336-GM Real Image C8051F336-GM label picture
Same model may have multiple batches, images only for reference.

C8051F336-GM

Part No C8051F336-GM
Manufacturer Silicon Labs
Catalog Embedded - Microcontrollers
Description Mixed Signal ISP Flash MCU Family
Datasheet
C8051F336-GM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Silicon Labs
Series C8051F33x
Packaging Tube
Core Processor 8051
Core Size 8-Bit
Speed 25MHz
Connectivity SMBus (2-Wire/I2C), SPI, UART/USART
Peripherals POR, PWM, Temp Sensor, WDT
Number of I/O 17
Program Memory Size 16KB (16K x 8)
Program Memory Type FLASH
RAM Size 768 x 8
Supply Voltage 2.7 V ~ 3.6 V
Data Converters A/D 16x10b; D/A 1x10b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 85°C (TA)
Package 20-VFQFN Exposed Pad
Manufacturer Package 20-QFN (4x4)
Win Source Part Number 1158573-C8051F336-GM
Manufacturer Homepage www.silabs.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian C8051F336-GM CAD Model

Description

The C8051F336-GM is an 8-bit core processor from Silicon Labs.

  • Device Popularity: low
  • Manufacturer Package: 20-QFN (4x4)
  • Mounting Type: Surface Mount (SMD)
  • Package: Tube
  • Speed: 25MHz
  • Connectivity: SMBus (2-Wire/I2C), SPI, and UART/USART
  • I/Os: 17
  • Peripherals: POR, PWM, Temp Sensor, and WDT
  • Program Memory Size: 16KB (16K x 8)
  • Program Memory Type: FLASH
  • RAM Size: 768 x 8
  • Data Converters: A/D 16x10b; D/A 1x10b
  • Oscillator Type: Internal
  • Supply Voltage: 2.7 V ~ 3.6 V
  • Supply and Demand Status: Limited
  • Counterfeit Risk: 34% chance in the open market.
