Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Sharp Microelectronics
Series S208
Package Tube
Product Status Obsolete
Mounting Type Through Hole
Circuit SPST-NO (1 Form A)
Output Type AC, Zero Cross
Voltage - Input 1.2VDC
Voltage - Load 80 V ~ 240 V
Load Current 8 A
Termination Style PC Pin
Package / Case 4-SIP
Supplier Device Package 4-SIP
Standard Package 25 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 662361-S208T02
Ultra Librarian 3D Model Ultra Librarian S208T02 CAD Model

Description

The S208T02 is a solid state relay from the S208 series by Sharp Microelectronics.

  • Circuit Configuration: SPST-NO (1 Form A)
  • Load Current Rating: 8 A
  • Voltage Range: 80 V to 240 V
  • Voltage Input: 1.2VDC
  • Output Type: Zero-Cross
  • Package: 4-SIP
  • Mounting: Through-Hole
  • Status: Obsolete
