PC817X1J000F Real Image PC817X1J000F Real Image
Same model may have multiple batches, images only for reference.
PC817X1J000F Real Image PC817X1J000F Real Image
PC817X1J000F Real Image PC817X1J000F Real Image
Same model may have multiple batches, images only for reference.

PC817X1J000F

Part No PC817X1J000F
Manufacturer Sharp Microelectronics
Catalog Optoisolators - Transistor, Photovoltaic Output
Description DIP 4pin General Purpose Photocoupler
Datasheet
PC817X1J000F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Tube
Part Status Obsolete(EOL)
Number of Channels 1
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Minimum) 80% @ 5mA
Current Transfer Ratio (Maximum) 160% @ 5mA
Rise / Fall Time (Typ) 4μs, 3μs
Input Type DC
Output Type Transistor
Output Voltage MAX 80V
Output Current per Channel 50mA
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Maximum) 50mA
Vce Saturation (Maximum) 200mV
Operating Temperature Range -30°C ~ 100°C
Mounting Style Through Hole
Package 4-DIP (0.300", 7.62mm)
Manufacturer Package 4-DIP
Win Source Part Number 1235776-PC817X1J000F
Manufacturer Homepage sharp-world.com/
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Consumer Electronics, Power Management
Ultra Librarian 3D Model Ultra Librarian PC817X1J000F CAD Model

Description

The Sharp Microelectronics PC817X1J000F is a DC input transistor output optocoupler that is widely used in various electronic devices.

  • Mounting Style: Through-hole
  • Operating Temperature: -30°C to 100°C
