DD100KB80 Real Image
Same model may have multiple batches, images only for reference.

DD100KB80

Part No DD100KB80
Manufacturer SanRex Corporation
Catalog Diodes, Rectifiers - Arrays
Description DIODE MODULE 800V 100A
Datasheet
DD100KB80 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr SanRex Corporation
Package Tray
Product Status Active
Diode Configuration 1 Pair Series Connection
Technology Standard
Voltage - DC Reverse (Vr) (Max) 800 V
Current - Average Rectified (Io) (per Diode) 100A
Voltage - Forward (Vf) (Max) @ If 1.35 V @ 320 A
Speed Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 30 mA @ 800 V
Operating Temperature - Junction -40°C ~ 150°C
Mounting Type Chassis Mount
Package / Case Module
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 584252-DD100KB80
Ultra Librarian 3D Model Ultra Librarian DD100KB80 CAD Model

Description

The 584252-DD100KB80 is a diode array designed for rectifier applications in electronic circuits.

  • Category: Discrete Semiconductor Products, Diodes-Rectifiers
  • Series: Standard
  • Voltage Rating (DC Reverse): 800V
  • Forward Voltage Rating: 1.35V @ 320A
  • Diode Configuration: 1 Pair in Series
  • Average Rectified Current Per Diode: 100A
  • Operating Temperature Range: -40°C to 150°C
  • Package: Module
  • Mounting: Chassis
  • Manufacturer: SanRex Corporation
  • Status: Active
