The TSW-105-24-G-D is a terminal strip from Samtec Inc., part of the TSW series. These terminal strips are designed for board-to-board connections and offer a reliable and cost-effective solution for various electronic applications. The TSW series is known for its versatility and ease of use.

Applications

• Board-to-board connections
• Signal routing
• Prototyping
• General electronic interconnections
• Telecommunications equipment

Features

• Dual row configuration
• 5 positions per row (10 total pins)
• 0.100" (2.54 mm) pitch
• Through-hole mounting
• Gold plated contacts
• Black insulator

Benefits

• Provides a reliable and robust board-to-board connection.
• Gold-plated contacts ensure excellent conductivity and corrosion resistance.
• Standard 0.100" pitch allows for easy integration with various components and boards.
• Through-hole mounting provides a secure mechanical connection.

Additional Details

The TSW-105-24-G-D is constructed with a high-temperature thermoplastic insulator. The contacts are made of beryllium copper. It can withstand a wide operating temperature range. It is often used with Samtec's mating connectors to create a complete interconnection system. The 'G' in the part number signifies Gold plating. The 'D' signifies dual row. The current rating is approximately 3A per contact. The voltage rating depends on the specific application and board spacing.
