The TSM-108-01-L-DV-014-M-TR is a terminal strip connector manufactured by Samtec Inc. These connectors are commonly used for board-to-board connections and are characterized by their high density and reliable performance.

Applications:

• Board-to-board connections
• Signal routing
• Interconnect solutions in various electronic devices
• Development boards
• Testing and prototyping

Features:

• High-density design
• Surface mountable
• Dual row configuration
• Gold-plated contacts
• Tape and reel packaging for automated assembly

Benefits:

• Provides reliable electrical connection
• Saves board space due to its compact size
• Suitable for high-volume manufacturing
• Ensures good signal integrity

Additional Details:

The TSM-108-01-L-DV-014-M-TR has 8 pins per row, arranged in a dual-row configuration. The -01 indicates the number of positions. The 'L' indicates the plating material, which is likely gold. 'DV' likely represents dual vertical row. 014 probably refers to the height above the board in inches. The '-M' suggests that it is a modified version and 'TR' implies tape and reel packaging. Key specifications include the contact resistance, insulation resistance, current rating, and voltage rating. The datasheet is crucial for obtaining the precise dimensions, materials, and electrical characteristics. The gold-plated contacts ensure good conductivity and resistance to corrosion. The tape and reel packaging is designed for automated pick-and-place assembly, reducing manufacturing costs. Correct soldering techniques and reflow profiles are essential for reliable connections, as outlined in Samtec's recommendations.
