The TMS-105-01-S-DV-P-TR is a surface mount terminal strip connector manufactured by Samtec. It is part of the TMS series, known for its high-density and reliable interconnect solutions. This connector is designed for board-to-board connections and is commonly used in a variety of electronic applications.

Applications

• Board-to-Board Connections: Used to connect two printed circuit boards (PCBs) together.
• Medical Equipment: Employed in medical devices requiring reliable and high-density connections.
• Industrial Automation: Used in control systems, sensors, and other industrial equipment.
• Telecommunications Equipment: Found in networking devices, routers, and switches.
• Consumer Electronics: Used in devices such as computers, laptops, and smartphones.

Features

• Number of Positions: 10 positions.
• Number of Rows: Dual row.
• Pitch: 0.050" (1.27 mm) pitch for high-density connections.
• Mounting Type: Surface mount.
• Termination Style: Solder tails for secure attachment to the PCB.
• Insulator Material: High-temperature thermoplastic for reflow soldering compatibility.
• Contact Material: Phosphor bronze for good conductivity and durability.
• Plating: Gold plating on the contacts for corrosion resistance and reliable performance.

Benefits

• High-Density Connections: Provides a large number of connections in a small space.
• Reliable Performance: Gold-plated contacts ensure reliable signal transmission.
• Easy Surface Mount Assembly: Designed for automated pick-and-place assembly.
• Durable Construction: Withstands harsh environments and repeated mating cycles.
• Reflow Soldering Compatibility: High-temperature thermoplastic allows for reflow soldering processes.

Additional Details

The TMS-105-01-S-DV-P-TR connector has a current rating of approximately 1 Amp per contact. The operating temperature range is typically -55°C to +125°C. The “-TR” suffix indicates that the connector is supplied on tape and reel for automated assembly. Refer to the Samtec datasheet for detailed specifications, dimensions, and recommended PCB layout.
