The SSW series connector from Samtec Inc. is a rectangular connector that features a receptacle connector type with forked contact type.

• Connector Type: receptacle
• Contact Type: forked
• Number of Positions: 56
• Positions Loaded: all positions
• Number of Rows: two
• Pitch-Mating: 0.100 inches (2.54mm)
• Application: board-to-board or cable style
• Contact Material: phosphor bronze
• Contact Finish Mating: gold
• Contact Finish Post: gold
• Current Rating: 4.7A per contact
• Temperature Range: -55°C to 125°C
• Mounting: through hole
• Packaging: bulk
• Standard Package: 1
• Insulation Material: liquid crystal polymer (LCP)
• Material Flammability Rating: UL94 V-0
