The Samtec Inc. SSQ series features a 50 position receptacle connector header with forked contact type.

• Positions: 50
• Contacts: Forked
• Positions Loaded: All
• Rows: 1
• Termination: Solder
• Fastening Type: Push-pull
• Package: Bulk
• Contact Material: Phosphor bronze
• Voltage Rating: 465VAC, 655VDC
• Mated Stacking Heights: Not specified
• Ingress Protection: Not applicable
• Material Flammability Rating: UL94 V-0
• Applications: Not specified
• Standard Package: 1
• Insulation Material: Liquid crystal polymer (LCP)
• Style: Board to board or cable
• Pitch - Mating: 0.100" (2.54mm)
• Contact Finish - Mating: Gold
• Contact Finish Thickness - Mating: 30.0µin (0.76µm)
• Contact Finish - Post: Tin
• Insulation Color: Black
• Mounting Type: Through hole
• Contact Length - Post: 0.194" (4.93mm)
• Insulation Height: 0.335" (8.51mm)
• Contact Shape: Square
• Temperature Range - Operating: -55°C ~ 125°C
• MSL Level: Not applicable
• Current Rating (Amps): Not specified
• REACH Status: REACH Unaffected
• HTSUS: 8536.69.4040
• Other Names: SAM1191-50
• Base Product Number: SSQ-150
