The Tiger Eye™ SFMC 1286421-SFMC-107-01-F-D-K-TR is a 14-position, 2-row, board-to-board or cable receptacle connector from Samtec Inc. It has a pitch of 0.050" (1.27mm) and features pick and place.

• Positions: 14
• Rows: 2
• Connection Style: Board-to-board or cable
• Connector Type: Receptacle
• Contact Type: Female Socket
• Positions Loaded: All
• Termination: Solder
• Fastening Type: Push-pull
• Package: Tape & Reel (TR)
• Contact Material: Beryllium copper
• Contact Finish: Gold
• Contact Finish Thickness: 3.00µin (0.076µm) (Mating)
• Contact Finish: Tin (Post)
• Insulation Material: Liquid crystal polymer (LCP)
• Insulation Color: Black
• Mounting Type: Through hole
• Row Spacing: 0.050" (1.27mm)
• Contact Length: 0.120" (3.05mm) (Post)
• Insulation Height: 0.180" (4.57mm)
