SEAF-30-07.5-L-04-2-A-K-TR

Name: SEAF-30-07.5-L-04-2-A-K-TR
Brand: Samtec Inc.
SKU: 1293902
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SEAF-30-07.5-L-04-2-A-K-TR
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Datasheet	SEAF-30-07.5-L-04-2-A-K-TR Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr	Samtec Inc.
Series	SEARAY™ SEAF
Package	Tape & Reel
Connector Type	High Density Array, Female
Number of Positions	120
Pitch	0.050" (1.27mm)
Number of Rows	4
Mounting	SMD (SMT)
Features	Board Guide, Pick and Place
Contact Finish	Gold
Contact Finish Thickness	10.0µin (0.25µm)
Mated Stacking Heights	9.5mm, 10.5mm, 11mm, 14mm, 14.5mm, 16.5mm, 18.5mm, 20.5mm
Height Above Board	0.297" (7.54mm)
Base Product Number	SEAF-30
Other Names	612-SEAF-30-07.5-L-04-2-A-K-TRCT,612-SEAF-30-07.5-L-04-2-A-K-TR,SEAF-30-07.5-L-04-2-A-K-TR,612-SEAF-30-07.5-L-04-2-A-K-TRDKR
Standard Package	275
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	1293902-SEAF-30-07.5-L-04-2-A-K-TR
Ultra Librarian 3D Model	Ultra Librarian SEAF-30-07.5-L-04-2-A-K-TR CAD Model

Alternative Products

Description

The Samtec Inc. electronic component with part number 1293902-SEAF-30-07.5-L-04-2-A-K-TR is a SEARAY™ SEAF connector.

Positions: 120
Connector Type: High density array, female
Rows: Four
Mounting Type: Surface mount (SMD)
Pitch for Mating: 0.050" (1.27mm)
Contact Finish: Gold
Height Above Board: 0.297" (7.54mm)
Package: Tape and reel
Mated Stacking Heights: 9.5mm, 10.5mm, 11mm, 14mm, 14.5mm, 16.5mm, 18.5mm, and 20.5mm
