The SEAF-30-05.0-L-04-1-A-LP-K-TR is a high-density, high-speed edge card socket from Samtec's SEARAY™ family, designed for applications requiring reliable signal integrity and space-saving connections. It features a surface mount termination and is provided on tape and reel for automated assembly. The LP designation indicates a low profile design.

Applications:

• High-speed backplanes
• Edge card connections for PCBs
• Data center equipment
• Networking and telecommunications
• Medical devices
• Test and measurement equipment

Features:

• High-Density Design: Provides a large number of signals in a compact footprint.
• Surface Mount Termination: Allows for automated assembly and reflow soldering processes.
• Edge Card Socket: Designed specifically for mating with edge cards.
• SEARAY™ Contact System: Offers high reliability and signal integrity.
• Tape and Reel Packaging: Suitable for automated pick-and-place assembly.
• Low Profile Design: The LP indicates a low profile design for height constrained applications.

Benefits:

• Increased Board Density: Enables more functionality in a smaller area.
• Reliable Connections: Ensures consistent performance in demanding environments.
• Simplified Assembly: Streamlines the manufacturing process.
• High-Speed Performance: Supports high data rates for modern applications.
• Design Flexibility: Compact size allows for greater board layout options.

Additional Details:

The SEAF-30-05.0-L-04-1-A-LP-K-TR features a 1.27 mm pitch and is constructed with high-quality materials for durability and optimal performance. The gold-plated contacts minimize signal loss and provide a reliable connection. This connector is designed for the demanding requirements of high-speed digital systems.

Consult the official Samtec datasheet for detailed specifications, including dimensions, electrical characteristics, and mating information.
